Touchscreen High Frequency 3kw Hybrid Solar Inverter 24 Volt

Tips:
Minimum order quantity (MOQ) ≥100 Pieces;
Samples can be sent for testing;
Feature:

Touch color screen display, intuitive parameter display

Enhancedinverter output power under PV mode

Standard main and auxiliary dual AC voltage sufficientpower output
Novel and fashionable RGB atmosphere lights indicator
Higher photovoltaic utilization under PV and grid powercomplements
EMl filtering and strong anti-interference technologyFrosted white appearance design

Availability:



Inquiry

Model:
GA3024SMH
Brand:
Techfine

BH Series 3KW High Frequency Touchscreen Hybrid Solar Inverter: Efficient and User-Friendly Solar Power Solution

Introducing the BH Series 3KW high frequency touchscreen hybrid solar inverter, designed to bring seamless efficiency and convenience to your home solar power needs. This versatile series includes six models—BH3024SMH, BH3624SMH, BH5548SMH, EA5548EMH, BH6248SMH, and BH11048SMH—each tailored for diverse energy requirements.

Engineered to maximize power under PV mode, the 3KW high frequency solar inverter supports dual AC voltage output, allowing flexible setup across multiple applications. With both 24V and 48V options, these inverters ensure reliability in any configuration, making them the ideal 24 volt solar inverter choice.

The BH Series offers an intuitive touchscreen interface with clear parameter displays, ensuring easy management and real-time visibility. Fashion-forward RGB indicator lights add a modern touch, while the frosted white exterior blends style with durability. Plus, advanced EMI filtering and strong anti-interference technology provide stable operation in challenging environments.

Choose the BH Series for smarter, more efficient solar energy management.

3kw hybrid solar inverter 3kw inverter solar 3kw hybrid inverter 24v solar inverter 24 volt solar inverter 3KW High Frequency Solar Inverter

Model		GA3024SMH
Input Formation		L+N+PE
ACInput		220/230/240VAC
Input VoltageRange		90-280VAC±3V(Normal Mode)185-264VAC±3V(UPS Mode）
Frequency		50/60Hz(Adaptive)
Rated Power		3000W
DualOutput Power		3000W
Second Load Cut Off Voltage		22V
Second Load Return Voltage		26V
Output Voltage(AC）		208/220/230/240VAC±5%
Output Frequency		50/60Hz±0.1%
Output Wave		Pure Sine Wave
Transfer Time(Adjustable）		10ms for Computer Equipment, 20ms for Household Equipment
Peak Power		6000VA
Overload Ability		Battery Mode : 21@102%~110% load 10s@110%-130% load 3s@130%-150% oad 400ms@>150% load
Grid connected peration	Output Voltage	208/220/230/240VAC±5% （Feed-in Grid Voltage Range:195-253VAC）
	Grid Voltage Range	195-253VAC
	Grid Frequency Range	50/60Hz±0.1% (Feed-in Grid Frequency Range:49-51+1Hz/59-61+1Hz）
	Output Current	13.6A
	Power Factor Range	＞0.99
Peak Efficiency(Battery Model		＞94%
Rated Voltage		24VDC
Constant Charging Voltage		28.2VDC
Float Charging Voltage		27VDC
PV Charging Method		MPPT
Max PVInput Power		5000W
PVInput Voltage Range		60~500VDC
MAX PV Input Voltage		500VDC
MAX PV Input Current		18A
MAX PV Charge Current		100A
MAX AC Charge Current		60A
MAX Charge Current		100A
LCD		Can display operating mode/load/input/output
RS232		5PIN/Pitch2.54mmBaud Rate 2400
Expansion Slot communication Interface		Lithium Battery BMS Communication Card,WIFI2x5PIN/Pitch2.54mm
ParallelInterface		Not Support Parallel
Operating Temperature		0℃~40℃
StorageTemperature		-15℃~60℃
Ork Altitude		No more than 1000m,lf1000m<,Rate power will lower,MAX 4000m, Refer
Operating Environment Humidity		Non condensing
Noise		＜50dB
LWH(mm）		495312125mm
