Online Ups 5kva 6 Kva 10KVA Backup UPS Uninterrupted Power Supply 6kva For Data Center

Share to:

Online Ups 5kva 6 Kva 10KVA Backup UPS Uninterrupted Power Supply 6kva For Data Center

Tips:
Samples can be sent for testing;
Minimum order quantity (MOQ) ≥100 Pieces;
Feature:
Max 12 A big charge current
1.0 output power factor
Up to 95.5% high efficiency

Availability:



Inquiry

Model:
CQ6K
Brand:
Techfine

Feature：

Pure sine wave output, online zero conversion time
Wide input frequency range adjustable from 40-70HZ
Output short circuit protection and overload protection
Full-time lightning protection, noise and surge protection
The LCD screen is to display the status parameters at a glance
The RS232 communication interface is applied
Double-sided circuit board design with higher safety and reliability
Various common technical parameters can be set on the panel

Online UPS CQ Series Detail

Backup Ups Uninterrupted Power Supply 6kva Online Ups 5kva 6 Kva 10kva Backup Ups ups with 4 hour backup large ups power supply portable ups computer ups battery

Models		CQ6K (S)
Phase		Single-phase
Capacity		6KVA / 6KW
Input
Voltage range		110 - 300VAC
Frequency range		50HZ/60HZ
Power factor		1
Output
Output voltage		220VAC±1% (208, 220, 230, 240 adjustable on LCD screen), 110VAC±1% Optional
Frequency range (battery mode)		50 Hz （60HZ selectable）± 0.25 Hz
Transfer		0ms
time
Wave form		Pure sine wave
Battery
Standard	Battery model	12V / 7AH（Standar) 12V /9AH（Optional)
	Quantity/DC Voltage	12PCS/144VDC
	Max. charging current	1A, 2A, 3A, 4A, 5A, 6A, 7A, 8A, 9A, 10A adjustable
Long-run	Battery model	Depends on the users
	DC Voltage	192VDC
	Max. charging current	1A, 2A ,3A, 4A, 5A, 6A, 7A, 8A, 9A, 10A, 11A, 12A adjustable
LCD or LED display		Load size, battery capacity, mains mode, battery mode, bypass mode, fault indication
Control management		Smart RS-232、SNMP optional

Models		CQ6K (S)
Phase		Single-phase
Capacity		6KVA / 6KW
Input
Voltage range		110 - 300VAC
Frequency range		50HZ/60HZ
Power factor		1
Output
Output voltage		220VAC±1% (208, 220, 230, 240 adjustable on LCD screen), 110VAC±1% Optional
Frequency range (battery mode)		50 Hz （60HZ selectable）± 0.25 Hz
Transfer		0ms
time
Wave form		Pure sine wave
Battery
Standard	Battery model	12V / 7AH（Standar) 12V /9AH（Optional)
	Quantity/DC Voltage	12PCS/144VDC
	Max. charging current	1A, 2A, 3A, 4A, 5A, 6A, 7A, 8A, 9A, 10A adjustable
Long-run	Battery model	Depends on the users
	DC Voltage	192VDC
	Max. charging current	1A, 2A ,3A, 4A, 5A, 6A, 7A, 8A, 9A, 10A, 11A, 12A adjustable
LCD or LED display		Load size, battery capacity, mains mode, battery mode, bypass mode, fault indication
Control management		Smart RS-232、SNMP optional
